Heating Design - Gas Systems

Designing, Fitting and Servicing Gas heating systems is a core service that we have been offering for more than 25 years – we have an established reputation for quality, service, and customer satisfaction.



One of the keys to a good heating system is a good boiler. We are one of the few Gold Accredited Installers for the Worcester Bosch Group and their range of products is one which we recommend that you can trust for quality and reliability. You don’t have to take our word for it - the Greenstar Gas Range wins Which? Best Buy for 6th consecutive year!!



We will install with a 7 year guarantee as standard – 8 years with a System Filter



The are 3 types of Boilers

  • Combi
  • System
  • Regular

Combi Boilers

A combination or ‘combi’ boiler is both a high efficiency water heater and a central heating boiler in a single compact unit. Combi boilers heat water directly from the mains when you turn on a tap, so you won’t need a hot water storage cylinder or a cold water storage tank in the roof space.

They are also very cost-effective and energy-efficient as water is heated instantly rather than being heated and then stored in a cylinder. An added benefit is that hot water is delivered at mains pressure, which means that you could get a powerful shower without the need for a separate pump.

  • Compact sizes make combi boilers perfect for smaller properties
  • Ideal where there is little or no loft space
  • No need for a hot water cylinder allows increased living space
  • No cold water storage tank frees up a loft for conversion
  • No risk of loft pipework freezing
  • Less pipework in the home makes installation typically cheaper

Worcester Greenstar CDi Classic Combi Gas Boiler

Top-of-the-range combi boiler with a market leading output of up to 42kW. Suitable for all homes with one or two bathrooms it has hot water flow rates of 17.2 litres/min and is renowned for its ease of installation, advanced features and future-proof technology. Advanced features include the ability to range-rate the CH output to perfectly match the home's requirement.



System Boilers

System boilers require a cylinder for storing hot water, however the major heating and hot water system components are built into the boiler itself, making it quicker and easier to install. In addition, there is no need for a tank in the loft, so it can be an option in a home with little or no loft space or where the space is earmarked for a conversion.

These boilers are also compatible with solar water heating systems, which deliver environmental benefits as well as lower energy bills.

  • Ideal for homes with more than one bathroom
  • Constant supply of hot water to any number of taps at the same time
  • No need for a loft tank, freeing up space and eliminating worries about leaks or frost damage
  • Economical to run
  • Built-in components makes installation quicker and neater

Regular Boilers

Regular boilers (sometimes known as traditional, conventional or heat only boilers) are ideally suited to homes that already have a traditional heating and hot water system which is linked to a separate hot water cylinder. These boilers also need a cold water storage tank in the loft to feed the hot water cylinder as well as a tank that maintains the water level of the central heating system.

A regular boiler may be the best option for replacing an existing boiler if the property has an older radiator system, as it might not be able to cope with the higher water pressure that is delivered by system or combi boilers.

  • Perfect for homes where a lot of hot water is used at the same time
  • Ideal where there are two or more bathrooms
  • A good option in areas where water pressure is low
  • Compatible with solar water heating systems for a lower carbon footprint and lower energy costs

Gas Boiler Overview (Worcester Greenstar)

Product Type Fuel House Comment
Greenstar i Combi Gas Small / Med
Greenstar Si Compact Combi Gas Small / Med Fits within a std kitchen cupboard
Greenstar CDi Classic Combi Gas Small / Med Market leading output of up to 42kW
Greenstar CDi Compact Combi Gas Med / Large Fits within a std kitchen cupboard
Greenstar CDi Highflow Combi Gas Med / Large Floor standing
Greenstar i System (9kW to 24kW) System Gas Med / Large Wall Mounted
Greenstar i System (27kW and 30kW) System Gas Med / Large Fits within a std kitchen cupboard
Greenstar CDi Classic System System Gas Large Wall Mounted
GB162 System Gas Large / Commercial Domestic & Commercial with Multi Cascade options

Greenstar Ri

(12kW to 24kW)

Regular Gas Small / Med Fits within a std kitchen cupboard

Greenstar Ri

(27kW & 30kW)

Regular Gas Med / Large Fits within a std kitchen cupboard
Greenstar CDi Classic Regular Regular Gas Large Top-performing regular boiler with outputs up to 40kW
Greenstar CDi FS Regular Regular Gas Large Floor standing, outputs up to 40kW



Greenstar i

Greenstar i combi boiler is the replacement for the well-established award-winning Greenstar i Junior, which has been installed in over 1 million homes across the UK.

Perfect for small to medium sized homes with one bathroom, the boilers' new features have been designed based on installer feedback. These boilers now include increased outputs, higher hot water flow rates of up to 12.3 litres/min, a user friendly control panel and a larger condensate siphon that eliminates the risk of condensate freezing.



Greenstar Si Compact

Greenstar Si Compact combi boiler is suitable for small to medium sized homes with one bathroom..With hot water flow rates of up to 12.3 litres/min, the Greenstar Si has a host of design features for ease of installation, use and servicing and can also fit within a standard kitchen cupboard.



Greenstar CDi Classic

Greenstar CDi Classic combi is the top-of-the-range combi boiler with a market leading output of up to 42kW. Suitable for all homes with one or two bathrooms, and hot water flow rates of 17.2 litres/min, this boiler is renowned for its ease of installation, advanced features and future-proof technology. Advanced features include the ability to range-rate the CH output to perfectly match the home's requirement.



Greenstar CDi Compact

Greenstar CDi Compact combi is the newest addition to the top-of-the-range CDi boiler series with DHW flow rates up to 14.7 l/min. Suitable for small, medium and large-sized homes with one or two bathrooms, this boiler can be installed in a standard kitchen cupboard. New performance-enhancing features include an LCD display control panel and key components positioned to provide easy access.



Greenstar CDi Highflow

Greenstar Highflow CDi combi is a well-established floor-standing combi boiler that is renowned for their industry-leading DHW flow rates of up to 25 litres/min.

Designed to make installation as straight forward as possible, this boiler is supplied with a pre-plumbing jig and has a wheel-in tray which allows the appliance to slide into place



Greenstar i System (9kW to 24kW)

Greenstar i System is the most popular wall-mounted system boiler with outputs up to 24kW. Suitable for a wide range of homes, this boiler comes with a steel wall-mounting jig that not only allows pipes to go behind the boiler but also the ability to pre-pipe all of the pipework before the boiler is placed on the wall.

The appliance can be used with a range of high efficiency Greenstore cylinders.



Greenstar i System (27kW and 30kW)

Greenstar i System is part of the latest generation of smaller and lighter boilers with outputs of 27kW and 30kW. This boiler, which can be fitted in a standard kitchen cupboard comes with a steel wall-mounting jig that not only allows pipes to go behind the boiler but also the ability to pre-pipe all of the pipework before the boiler is placed on the wall.The appliance can be used with a range of high efficiency Greenstore cylinders.



Greenstar CDi Classic System

Greenstar CDi Classic System is a top-of-the-range system boiler with outputs up to 34kW. Suitable for larger homes typically with more than three bedrooms, this boiler comes with a steel wall-mounting jig that not only allows pipes to go behind the boiler but also the ability to pre-pipe all of the pipework before the boiler is placed on the wall.

The appliance can be used with a range of high efficiency Greenstore cylinders.



GB162

The GB162 boiler is perfect for both large domestic and commercial applications.

This boiler has outputs of 50, 65, 80 and 100kW, with the ability to cascade up to 800kW as part of a multi-boiler 'cascade' system. Its compact dimensions make it especially suitable for installations where space is restricted - for larger heat demands the GB162 can be easily combined in any combination of  2 to 8 boilers either in-line or back-to-back, using the Bosch cascade kits.



Greenstar Ri (12kW to 24kW)

The Greenstar Ri is a compact regular boiler with outputs up to 24kW.

Suitable for small and medium-sized homes, this boiler can be installed in a standard kitchen cupboard. The appliance can be used with a range of high efficiency Greenstore cylinders.



Greenstar Ri (27kW and 30kW)

Our Greenstar Ri is part of a new generation of compact regular boilers with outputs of 27 & 30kW. Suitable for medium and large-sized homes, this boiler can be installed in a standard kitchen cupboard. The appliance can be used with a range of high efficiency Greenstore cylinders. By using the optional Greenstar Wiring Centre, this boiler can be used with a wider choice of controls.



Greenstar CDi Classic Regular

Greenstar CDi Classic Regular is a top-performing regular boiler with outputs up to 40kW. Suitable for larger homes typically with more than three bedrooms, this boiler comes with a steel wall-mounting jig that not only allows pipes to go behind the boiler but also the ability to pre-pipe all of the pipework before the boiler is placed on the wall.

The appliance can be used with a range of high efficiency Greenstore cylinders.



Greenstar CDi FS Regular

Greenstar FS CDi Regular is a floor standing boiler with outputs up to 40kW.

Suitable for large properties, this boiler is a perfect replacement for an older floor standing boiler and is supplied with a pre-plumbing jig and has a wheel-in tray allowing the appliance to be easily slid into place.

The appliance can be used with a range of high efficiency Greenstore cylinders.

Cylinder Overview (Worcester Greenstore)

The Greenstore range of hot water cylinders by Worcester Bosch perfectly complements the Greenstar system of regular boilers.



A cylinder is simply a tank that will store your hot water and pass it through taps and showers when required.



You can choose from two types of cylinder.

  1. A cylinder for use with a boiler
  2. A cylinder which allows you to add solar water heating to your system.



With a 25 year guarantee, Greenstore Worcester Bosch cylinders are manufactured by Bosch ensuring the highest quality. They are made with 100% recyclable components helping you to protect the environment.



Greenstore unvented cylinders from Worcester Bosch offer significant performance improvements over traditional cylinders.

  • Fast re-heat times
  • Significant energy savings over traditional cylinders.
  • Wide range of capacities from 90 to 300 litres so it’s easy to find a size that suits
  • Highly insulated to reduce loss of heat and will give you the hot water you need quickly
